Manufacturer:    Diotec Semiconductor
Product Category:    Digital Transistors
Configuration:    Dual
Transistor Polarity:    NPN, PNP
Typical Input Resistor:    22 kOhms
Typical Resistor Ratio:    1
Mounting Style:    SMD/SMT
Package / Case:    SOT-363
DC Collector/Base Gain hfe Min:    70 at 5 mA, 5 V
Collector- Emitter Voltage VCEO Max:    60 V
Continuous Collector Current:    100 mA
Pd - Power Dissipation:    200 mW
Minimum Operating Temperature:    - 55 C
Maximum Operating Temperature:    + 150 C
Series:    BCXXX
Packaging:    Reel
Packaging:    Cut Tape
Packaging:    MouseReel
Brand:    Diotec Semiconductor
Emitter- Base Voltage VEBO:    6 V
Maximum DC Collector Current:    100 mA
Product Type:    Digital Transistors
Subcategory:    Transistors
Tradename:    BCR22PN
Unit Weight:    0.001058 oz
